Description
| Max Strip Width | 25 mm |
| Strip Thickness | 0.3-1.0 mm |
| Press Capacity | 8 tons |
| Press Stroke | 18 mm |
| Slide Capacity | 1.8 tons |
| Slide Stroke (double cams) | 37 mm |
| Slide Quantity | 4 sets |
| Max Feed Speed | 30 meters/min. |
| Control | Schneider CNC control |
| Axes | 2, cam and feed |
| Machine Dimension (cm) | 135 x 87 x 165 |
| Machine Weight | 1200 KGS |
| Power | 380V |
