Description
| Number Of Axis | 2 axis |
| Wire Size Range | Φ0.15-0.8 mm |
| Max. Outside Diameter | Φ20 mm |
| Max. Feeding Speed | 150 m/min |
| Spring Index | 3 |
| Feeding Roller Pairs | 1 pair |
| Max. Production Rate | 400 pcs/min |
| Feeding Motor | 1.0 kw |
| Cam Motor | 1.0 kw |
| Pitch Motor | 0.40 kw |
| Dimension(LxWxH) | 950x1000x1500 mm |
| Weight | 350 kgs |
