Description
| Number Of Axis | 2 axis |
| Wire Size Range | Φ0.8-3.0 mm |
| Max. Outside Diameter | Φ70 mm |
| Max. Feeding Speed | 120 m/min |
| Feeding Roller Pairs | 2 pairs |
| Feeding Motor | 2.7 kw |
| Cam Motor | 2.7 kw |
| Pitch Motor | 0.75 |
| Dimension(LxWxH) | 1150x1300x1750 mm |
| Weight | 1200 kgs |
