Description
| Number Of Axis | 5 axis |
| Wire Size Range | Φ1.6-4.5 mm |
| Max. Outside Diameter | Φ80 mm |
| Max. Feeding Speed | 96 m/min |
| Spring Index | 3 |
| Feeding Roller Pairs | 3 pairs |
| Feeding Motor | 5.5 kw |
| Upper Cutter Motor | 2.7 kw |
| Under Cutter Motor | 2.7 kw |
| Cam Motor | 2.7 kw |
| Pitch Motor | 1.5 kw |
| Dimension(LxWxH) | 1250x1400x1850 mm |
| Weight | 1900 kgs |
