Description
| Machine Body Dimension(mm) | (Electronic Control Box And Screen Excluded) | Length:1800mm x Depth:1670mm x Height:2500mm |
| Safety Operation Location Area | (mm) | Length:12300mm x Depth:10000mm |
| Machine Weight | (kgs) | 4650kgs |
| Wire Capacity | (mm) | Ø2.4~6.0mm |
| Max. Spring O .D. | (mm) | Ø100mm |
| Feed Speed | (m/min) | 80m/min |
| Production Speed | (pcs/min) | 175pcs/min |
| Tensile Strength | (N/mm2) | 2000 N/mm2 |
| Spring Index | ≧3 |
